Engenius Senao 200 mw PCMCIA Card 2511-CD-PLUS


return to store

Click for our price


PDF manual


Features Benefits
Up to 23dBm(200mW) RF Output Power
Long operating range, up to three times range of standard products

11Mbps IEEE 802.11b Compliant
Full Interoperable with IEEE 802.11b

Automatic data rate scaling at 11, 5.5, 2 and 1 Mbps
Optimized throughput, range and connectivity

Improved 64/128-bit WEP Engine Significantly improved throughput

Wide coverage range up to 1200 meters in open space Wireless connectivity for all your computers

Advanced Power Management Extended battery life

Plug and Play PC Card interface Easy installation

Significantly improved indoor multi-path distortion Higher link quality in indoor environment

11Mbps data transfer rate High-speed data transmission

11 Mbps: 300m/450m
5.5 Mbps: 400m/600m
2 Mbps: 500m/750m
1 Mbps: 800m/1200m

Rec. Sensitivity (@FER=0.08)
11 Mbps <-89dbm
5.5 Mbps <-91dbm
2 Mbps <-93dbm
1 Mbps <-95dbm
Network Information
Network Architecture: Support ad-hoc, peer-to-peer networks and infrastructure communications to wired Ethernet networks via Access Point
Drivers: Windows 95/98/ME/2000/NT 4.0/CE/XP
Access Protocol: CSMA/CA
Roaming: IEEE802.11b compliant
Security: 64/128-bit WEP data encryption

Frequency Band: 2.4 2.484 GHz
Radio Type: Direct Sequence Spread Spectrum (DSSS)
Modulation: CCK (11, 5.5Mbps) DQPSK (2Mbps) DBPSK (1Mbps)
Operation Channels: 11 for North America, 14 for Japan, 13 for Europe, 2 for Spain, 4 for France
RF Output Power: 23dBm(200mW)--FCC
Antenna:Integrated, with built-in diversity
